Fixed Port

24x10/100/1000M RJ45 port

4xCOMBO optical port

Network Protocol

IEEE 802.3 Ethernet Medium Access Control Protocol

IEEE 802.3i 10BASE-T Ethernet

IEEE 802.3u 100BASE-TX Fast Ethernet

IEEE 802.3ab 1000BASE-T Gigabit Ethernet

IEEE 802.3z 1000BASE-X Gigabit Fiber Optic Ethernet

Port Characteristics

10/100/1000BaseT(X) auto-detect, full/half-duplex MDI/MDI-X adaptive

Forwarding Mode

Store-and-forward (full wire speed)

Backplane Bandwidth

56Gbps (non-blocking)

Packet Forwarding Rate

40.32Mpps

Supports 9K jumbo frame transmission

MAC Address Table

8K

Packet Forwarding Cache

4.1M

Transmission Distance

10BASE-T: Cat3,4,5 UTP(≤250m)

100BASE-TX: Cat5 or later UTP(≤150m)

1000BASE-TX: Cat6 or later UTP(≤150m)

SFP: Support 100/1000M single-mode and multi-mode optical modules, maximum distance ≤120km (depending on the optical module).

Power Consumption

Standby Power Consumption：≤30W；

LED

PWR:Power LED

1~28:(Link LED=10/100M Link、1000M LED=Gigabit Link)

SYS: System LED

Input Mode

Built-in Power AC：100～240V 50-60Hz 1A

Operation Environment

Operating temperature: -10℃～55℃;

Storage temperature: -40℃～75℃;

Operating humidity: 5%～90% RH without condensation

Storage humidity: 5%～95% RH non-condensing

Size (LxWxH)

Product size: 440x200x45mm

Package size: 513x300x95mm

N.W./G.W (kg)

2.2kg/3.5kg

Lightning

surge protection level

3KV 8/20us;

IP30

Installation

Desktop（optional external wall hanger parts）

Certification

CE mark, commercial; CE/LVD EN60950;
FCC Part 15 Class B; RoHS;

Warranty

Whole device for 1 year(Accessories not included)
